型號
model

功率
power
(KW)

電流
current
(A)

電壓
Voltage
(V)

頻率
Frequency
(HZ)

轉速
speed
(r/min)

工作
方式
Duty Type
(S₂)

制動
力矩
Braking torque
(N.M)

堵轉電流
額定電流
(倍)
Braking current/
Rated current
(times)

堵轉轉距
額定轉距
(倍)
Braking torque/
Rated torque
(times)

最大轉距
額定轉距
(倍)
Maximum torque/
Rated torque
(times)

重量
Weight
(kg)

YPE400S₂-4Z

0.4

0.93/1.86

440/220

60

1700

30min

6.8

5

1.8

2.0

13

1.1/2.2

400/200

50

1380

0.93/1.86

460/230

60

1700

1.25

380

60

1680

YPE750S₂-4Z

0.75

2.0/4.0

440/220

60

1700

30min

10.4

5

1.8

2.0

14

2.2/4.1

400/200

50

1380

2.0/4.0

460/230

60

1700

4.0

220

60

1680

2.45

380

60

1680

2.2

400

60

1680

2.4

415

50

1380

YPE1100S₂-4Z

1.1

2.5/5.2

440/220

60

1700

30min

15.2

5

2.0

2.5

21

2.7/5.4

400/200

50

1380

3.2

415

50

1420

2.5/5.2

460/230

60

1700

YPE1500S₂-4Z

1.5

4.0/7.8

440/220

50

1700

30min

20.8

5

2.0

2.5

32

4.5/8.2

400/200

50

1380

4.0/7.8

460/230

60

1700

3.0

500

50

1380

2.3

660

50

1430

YPE2200S₂-4Z

2.2

5.6/10.4

440/200

60

1700

30min

30.4

5

2.0

2.5

33

6.0/11

400/200

50

1380

5.6/10.4

460/230

60

1700

5.84

380

60

1680

YPE3000S₂-4Z

3.0

7.4/14.8

440/220

60

1700

30min

41.6

5

2.0

2.5

34

8.0/15.5

400/200

50

1380

7.4/14.8

460/230

60

1700

型號
Model

安裝尺寸Installation dimensions

外形尺寸Contour dimensions

D
(h6)

G
(h9)

GD
(h9)

F

N
(h7)

p

M
(±0.2)

E

R

S

T

L

LB

LA

AC

DA

KL

YPE400S₂-4Z

14

11

5

5

180

235

215

30

6

11

3

163

91

15

196

61

148

YPE750S₂-4Z

19

16

5

5

180

235

215

30

6

11

3

163

93

15

196

61

148

YPE1100S₂-4Z

19

16

5

5

230

290

265

50

6

14

4

205

108

13

233

61

168

YPE1500S₂-4Z

24

20

7

8

250

325

300

50

6

14

5

220

122

15

268

61

183

YPE2200S₂-4Z

24

20

7

8

250

325

300

50

6

14

5

220

122

15

268

61

183

YPE3000S₂-4Z

24

20

7

8

250

325

300

50

6

14

5

220

122

15

268

61

183
